Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle
Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle additional 1Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle additional 2Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle additional 3Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle additional 4Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle additional 5Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle additional 6
Next
Previous
10 Year Guarantee

£4,583.32 ex VAT£5,499.98 inc VAT

Out of Stock

If you would like to be emailed when this product is back in stock, please enter your email address below.

10 Year Guarantee

Product features

  • Smart solar generation & storage
  • Essential backup power capability
  • Modular system expansion
  • Plug-and-play wiring
  • Hybrid inverter & battery bundle
  • Built-in Wi-Fi monitoring
  • Essential junction box included
  • IP65 weather-resistant design
Product code: H1+EP5H
Feefo badgeFeefo Gold Trusted Service Award
Description

The Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, EP5-H Batteries & ESS EP Junction Box Bundle gives you solar, storage, and backup power in one ultra-efficient, future-proofed system. This complete package includes the highly advanced H1 G2 hybrid inverter, high-performance Fox ESS EP5-H high-voltage batteries, and the essential EP Junction Box, giving you a fully integrated solution designed for maximum energy savings, exceptional reliability and long-term scalability - no need to source separate components.

Fox ESS H1 G2 Hybrid Inverter

  • Powerful & Compact: Delivers a 3.68 kW single-phase output with high conversion efficiency, ideal for residential solar-plus-storage systems
  • Reliable Backup with EPS: Built-in Emergency Power Supply provides essential load support during grid outages (battery required)
  • Dual MPPT Trackers: Two independent MPPT inputs maximise solar generation across varying roof orientations
  • Durable Build: IP65-rated enclosure suitable for both indoor and outdoor installation
  • Smart Connectivity: Includes Wi-Fi monitoring module as standard, with LAN/4G datalogger options and RS485, CAN, USB communication ports
  • Long-Term Assurance: Backed by up to a 10-year warranty (registration and regional terms may apply)
  • Dimensions: W: 434mm x H: 418mm x D: 185mm | Weight: 22kg

Fox ESS EP5-H 5.18 kWh Li-ion Batteries

  • Generous capacity per unit: Provides 5.18 kWh of energy per high-voltage battery module
  • Scalable storage system: Connect up to 4 units in parallel for a total capacity of approximately 20.7 kWh
  • Built-in heater for cold climates: Self-heating functionality enables safe charging and discharging even in sub-zero temperatures
  • High efficiency & performance: Offers around 95% round-trip efficiency with a 90% depth of discharge
  • Long lifecycle: Delivers over 4,000 cycles at rated DoD for dependable long-term storage
  • Weather-protected & flexible installation: IP65-rated housing suitable for indoor or outdoor mounting
  • Slim, wall- or floor-mountable design: Only 147 mm deep, ideal for compact utility areas
  • High-voltage, efficient architecture: Operates at a nominal voltage of 192 V, fully compatible with Fox ESS hybrid and AC inverters
  • Safe, low-maintenance operation: Uses LiFePO₄ chemistry with passive cooling and no moving parts for silent, stable performance
  • Compact dimensions & manageable weight: 380mm x 625mm x 147mm | Weight (approx.): 50.5 kg per module

Fox ESS EP Junction Box

  • Essential integration: Required for safely connecting multiple EP-series batteries
  • Central communication hub: Manages data flow between battery stack and inverter
  • Scalable architecture: Supports up to 4× EP5-H batteries per stack (≈20.7 kWh total)
  • Plug-and-play wiring: Preconfigured terminals ensure fast, error-free installation
  • IP65 protection: Weather-resistant for indoor or outdoor mounting
  • Built-in safety features: Provides correct HV routing, overcurrent protection and stable system operation
  • Future-proof expansion: Easily add more batteries as storage needs grow
  • Dimensions: W: 223mm x H: 246mm x D: 89mm

Bundle Contents: 1x Fox ESS H1 G2 3.68 kW Single‑Phase Hybrid Inverter, 3x Fox ESS EP5‑H 5.18 kWh Li‑ion Batteries, each with integrated heating & 1x Fox ESS EP Junction Box (for parallel connection of multiple batteries).

  • Complete & Ready to Install: Includes inverter, three batteries, and junction box - everything needed for a smooth installation
  • Reliable in Any Climate: Battery heating ensures functionality in low temperatures - a must for colder regions
  • High Efficiency & Longevity: LFP chemistry offers safe, durable performance with thousands of charge-discharge cycles
  • Seamless Expansion: Modular design enables straightforward battery addition to scale storage as needed
  • Smart & Connected: Built-in Wi‑Fi and cloud monitoring make system management intuitive and accessible
  • Long-Term Assurance: 10-year warranties on both inverter and batteries underscore solid investment value

Code: H1+EP5H
